WOODPECKER PILLAR B
WOODPECKER PILLAR B

WOODPECKER PILLAR B | Contemporary Garden Light

SP-280B / SP-360B / SP-440B | Vertical Solar Integration | 180° Pathway Lighting
Model Number
SP-280B
SP-440B
LED Power
25W
60W
Luminous Flux
4,500lm
10,800lm
Solar Panel
188W 18V MONO
376W 18V MONO
LiFePO4 Battery
12.8V 24AH
12.8V 48AH
Send inquiry
More info
WOODPECKER PILLAR B
WOODPECKER PILLAR B

WOODPECKER PILLAR B | Contemporary Garden Light

SP-280B / SP-360B / SP-440B | Vertical Solar Integration | 180° Pathway Lighting
Model Number
SP-280B
SP-440B
LED Power
25W
60W
Luminous Flux
4,500lm
10,800lm
Solar Panel
188W 18V MONO
376W 18V MONO
LiFePO4 Battery
12.8V 24AH
12.8V 48AH
Send inquiry
More info

WOODPECKER PILLAR B brings a more contemporary expression to solar garden and pathway lighting. Its sculpted upper profile, vertical solar panels and integrated light source create a distinctive architectural presence while maintaining the clean proportions of the PILLAR family.


Designed for pedestrian paths, residential roads and landscaped spaces, PILLAR B combines high-efficiency LED lighting, vertical solar generation, microwave motion sensing and LiFePO4 energy storage in a compact integrated system. Its 180° light distribution provides controlled illumination suited to linear pathways and garden environments.


Available in 2.8m, 3.6m and 4.4m configurations, PILLAR B can be specified in Black, Grey, White or Matt Silver, with Oak, Walnut and Pine finishes available for more expressive landscape applications. The result is a solar lighting solution that balances visual character, functional precision and outdoor reliability.

Key Componente & Advantages

LiFePo4 Battery
Grade A+ Battery cell with high uniformity of internal resistance and charging and discharging.
Programmable by Remote
The lighting program can be modified anytime by remote control according to customers' requirement.
Vertical Solar Panels
Capture sunlight from multiple angles for improved energy generation.
High Brightness LED
200lm/W high-efficiency LED delivers powerful illumination with low energy consumption.
Microwave Motion Sensor
Detects movement and automatically adjusts brightness to reduce unnecessary energy use.
IP65 & IK08 Protection
Engineered with IP65 ingress protection and IK08 impact resistance for reliable outdoor use.

Main Specification

Model Number
SP-280B
SP-360B
SP-440B
Dimension
188*188*2800mm
188*188*3600mm
188*188*4400mm
Max LED Power
25W as factory set
38W as factory set
60W as factory set
Luminous Flux
4,500lm
7,200lm
10,800lm
LED Chips
SMD5050 24 nos 5W/LED max
•
•
LED Lifetime
100,000H
•
•
CRI
Ra ≥76
•
•
CCT
2200K~6000K
•
•
CCT Range
2200K~6500K
•
•
Solar Panel
188W 18V MONO
248W 18V MONO
376W 18V MONO
Cell Efficiency
22.5%
•
•
Solar Panel Lifetime
>20 years
•
•
Nominal Capacity
12.8V 24AH
12.8V 36AH
12.8V 48AH
Battery Lifetime
4,000 cycles D.O.D 80%
•
•
Light Distribution
180° / SCL Type II/III (long)
•
•
IP&IK Protection
IP65 IK08
•
•
Color
Grey / Black / Customized
•
•
Sensor Type
Microwave
•
•
Warranty
5 Years
•
•

Main Specification

Model Number
Dimension
Max LED Power
Luminous Flux
LED Chips
LED Lifetime
CRI
CCT
CCT Range
Solar Panel
Cell Efficiency
Solar Panel Lifetime
Nominal Capacity
Battery Lifetime
Light Distribution
IP&IK Protection
Color
Sensor Type
Warranty
SP-280B
SP-360B
SP-440B
188*188*2800mm
188*188*3600mm
188*188*4400mm
25W as factory set
38W as factory set
60W as factory set
4,500lm
7,200lm
10,800lm
SMD5050 24 nos 5W/LED max
•
•
100,000H
•
•
Ra ≥76
•
•
2200K~6000K
•
•
2200K~6500K
•
•
188W 18V MONO
248W 18V MONO
376W 18V MONO
22.5%
•
•
>20 years
•
•
12.8V 24AH
12.8V 36AH
12.8V 48AH
4,000 cycles D.O.D 80%
•
•
180° / SCL Type II/III (long)
•
•
IP65 IK08
•
•
Grey / Black / Customized
•
•
Microwave
•
•
5 Years
•
•

Download

Data Sheet
User Manual
Certificate
1.
Datasheet of SOLVERT PILLARS
*.pdf

Projects Cases

Vertical Solar Street Lights in Pakistan
1000 sets of light poles and 2000 sets of cylindrical solar street lights are installed in Pakistan by DHA project
26-09-2025
More...
Vertical Solar Light Poles in Mexico
463 sets of high-power vertical light poles were installed at the Mexican Customs Terminal.
27-03-2025
More...
Vertical solar street light in Oman
Oman has enhanced its urban road lighting by installing 75 hexagonal cylindrical solar street lights. These energy-efficient systems provide reliable illumination, improving road safety for both drivers and pedestrians.
25-03-2025
More...
Vertical Solar Street Lights in Abu Dhabi
179 vertical solar street lights for Solar Roadway Lighting Project in Abu Dhabi,UAE.
24-03-2025
More...

Projects Cases

Vertical Solar Street Lights in Pakistan
1000 sets of light poles and 2000 sets of cylindrical solar street lights are installed in Pakistan by DHA project
26-09-2025
View More
Vertical Solar Light Poles in Mexico
463 sets of high-power vertical light poles were installed at the Mexican Customs Terminal.
27-03-2025
View More
Vertical solar street light in Oman
Oman has enhanced its urban road lighting by installing 75 hexagonal cylindrical solar street lights. These energy-efficient systems provide reliable illumination, improving road safety for both drivers and pedestrians.
25-03-2025
View More
Vertical Solar Street Lights in Abu Dhabi
179 vertical solar street lights for Solar Roadway Lighting Project in Abu Dhabi,UAE.
24-03-2025
View More

You May Ask

1.
What's the material of solar garden light?
Auroras's solar garden lights adopt UV-resistant polycarbonate and die cast aluminum.
2.
What's the CCT available for solar garden light?
Auroras's solar garden lights available in dual CCT, optional in 2700K+3000K, 3000K+4000K, 3000K+6000K, switchable by a remote control.
3.
What's the benefit of tilted solar panels of ATHENA?
It can prevent snow and rain, which helps improve charging efficiency.
4.
Can solar garden light connect with 220V AC?
ATHENA  is available in hybrid solution(DC+AC).
5.
Which solar garden light has IDA certification?
THEMIS and AUGE are IDA approved.
6.
Can I increase the battery of ATHENA or THEMIS ?
Yes, THEMIS battery can be doubled, but due to the limited space, Athena battery cannot be increased.
7.
Do you have the 60mm bracket for the solar garden light?
Yes, the standard size is 76mm. while there is an extra adapter, so the solar post light can be mounted on the pole with 60mm diameter.
8.
Can i turn ON/OFF the motion sensor?
Yes, it can be ON/OFF settable by remote control.
9.
Can you make ATHENA in 220V hybrid verision?
Yes, our ATHENA can be Hybrid version. When the battery is insufficient, it automatically triggers the mains to supply power.  the price will be 30usd more per unit.
10.
Is the battery and controller easily replaceable?
Yes, it can replaced / repaired easily.
