Microwave Sensor Outdoor Solar Lawn Light

Model Name

SC-80B

SC-100B

Luminous Flux

1,680lm

2,480lm

Solar Panel

38Wp 18V

54Wp 18V

LiFePO4 Battery

3.2V 36AH

3.2V 60AH

Warranty

5 Years

The SOLVERT Cube series is a high-performance integrated solar lawn light designed to bring a modern, minimalist aesthetic to premium landscapes. Crafted from high-grade aluminum alloy with a hot-dip galvanized treatment, this solar courtyard bollard light offers exceptional structural integrity and corrosion resistance. Built for durability, the series boasts an IP65 waterproof rating and IK08 impact resistance, ensuring reliable operation in demanding outdoor environments.

Technically, the Cube series integrates advanced LED optics with high-efficiency vertical solar modules, maintaining a sleek profile without traditional flat panels. Each unit features a microwave motion sensor for intelligent energy management, providing bright illumination upon detection. Available in customizable finishes—including professional black, contemporary gray, and natural wood grain—this solar pathway post lamp is the ideal solution for parks, residential paths, and pedestrian walkways where style and sustainable performance are paramount.

Key Componente & Advantages

Programmable by Remote

The lighting program can be modified anytime by remote control according to customers' requirement.

IP65 Waterproof

IP65 rating provides superior protection against dust and water, ensuring reliable performance in various outdoor conditions.

High Efficiency LED

High-brightness LED chips provide superior illumination, enhancing visibility and energy efficiency.

Long LifeTime Battery

Quality lithium battery Long-lasting reduce maintenance costs and increase system reliability.

Motion Sensor

PIR or microwave sensor could be enabled to save more energy and extend the lifetime and more days autonomy.

360° Full Day Charging

Half area of round solar tube is facing to sun all the time to ensure continous charging all day long, generating more power.

Main Specification

Model Name

SC-80B

SC-100B

Peak LED Power

12W

Luminous Flux

1,680lm

2,480lm

Solar Panel

38Wp 18V

54Wp 18V

Battery Capacity

3.2V 36AH

3.2V 60AH

Motion Sensor

Microwave sensor Builtin

●

Dimension

160*160*80mm

160*160*100mm

Charging Time

5 Hours

●

Discharging Time

24 Hours

●

Fixture Color

Black/Oak/Walnut//Pine

●

IP & IK Rate

IP67 IK08

●

Certificates

CE RoHS

●

Warranty

5 Years

●

Main Specification

Model Name

Peak LED Power

Luminous Flux

Solar Panel

Battery Capacity

Motion Sensor

Dimension

Charging Time

Discharging Time

Fixture Color

IP & IK Rate

Certificates

Warranty

SC-80B

SC-100B

12W

1,680lm

2,480lm

38Wp 18V

54Wp 18V

3.2V 36AH

3.2V 60AH

Microwave sensor Builtin

●

160*160*80mm

160*160*100mm

5 Hours

●

24 Hours

●

Black/Oak/Walnut//Pine

●

IP67 IK08

●

CE RoHS

●

5 Years

●

Download

Data Sheet

User Manual

Certificate

Datasheet of SOVERT CUBE

*.pdf

Download

You May Ask

Can you change the height of the pole?

Yes, the height of the SkyBeam solar lighting column can be modified according to your requirements. For example, our standard height is 3200mm, then we can have 3300mm, 3400mm etc any heights as you wish.

What is the max height of this SkyBeam solar pole light?

The regular height of SkyBeam is 6M max due to the features of aluminum alloy. so we can use aluminum alloy to produce this solar pole light for all the heights less than 6 meters, for more than 6 meters height, the pole material will be steel instead of aluminum alloy, and height could be up to 10 meters even 12 meters as required.

Can you lift up the light head a bit? i don't like the horizontal design.

Yes, We can modify the design as you require. No problem.

Can i engrave my LOGO on this SkyBeam light pole?

Yes, Sure, We can use laser machine to engrave your logo on the light, And it is free of charge completely.

Can i increase or descrease the numbers of vertical PV module?

Yes, We can use the suitable size of PV module according to the height of pole. And the cost of the pole will be different.

Where is the lithium battery build?

The battery is built inside of the pole at the bottom part for easy accessing for maintenance or replacement. We can can put the battery into the light arm as long as the battery size is suitable.

Is there a motion sensor in the pole? And where it is?

Yes, The motion senor is available and it is equipped in the light head, It can be PIR motion sensor and also can be microwave sensor.

Can you use a lithium battery with much bigger capacity?

Yes, in the default configuration of the solar lighting pole, The battery capacity is based on our recommendation. We can use bigger lithium battery for more days automony as you require.

Can i use steel pole instead of aluminum alloy for cheaper price?

Yes, the price of using steel pole is much cheaper than using aluminum pole, while the steel pole will be much heavier and not so smooth finishing than aluminum pole.

10.

What LED optics do you use? Do you have IES?

The best led optics from LEDil are equipped as the standard optic for SkyBeam Vertical Solar Pole Light. There are more than 20 pcs of optics with different lighting performance to satisy any lighting requirement for your projects.
